Stream in Stunning Clarity: Introducing the Blackmagic Design Web Presenter
,
SDI Video Inputs
1
SDI Video Outputs
1 x loop out, 1 x monitor out.
SDI Rates
1.5G, 3G, 6G, 12G
HDMI Video Outputs
1 x monitor out
Webcam Output
1 x USB-C up to 2160p60
Ethernet
Ethernet supports 10/100/1000 BaseT for live streaming, software control and software updates.
Standards
HD Video Input Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
Ultra HD Video Input Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
Video Input Color Space
Rec.601, Rec.709, Rec.2020
3G SDI
Auto detects SMPTE level A or B on SDI input.
SDI and HDMI Monitor Out Video Standards
1080p50, 1080p59.94, 1080p60
Video Streaming Standards
720p25, 720p30, 720p50, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
Streaming
Direct Streaming
Blackmagic Web Presenter 4K supports direct live streaming over ethernet using Real Time Messaging Protocol (RTMP).
Closed Captions
Web Presenter 4K supports embedding CEA‑608 and CEA‑708 closed captions in your live RTMP stream.
Control
Control Panel
Built in control panel with 2.2 inch color display for video preview, audio meters and status.
Device Control
Front panel, USB‑C or ethernet.
Software
Compatible Services and Software
YouTube Live, Facebook Live, Twitter, Twitch, Skype, Microsoft Teams, Open Broadcaster and Wowza Streaming Engine.
Operating Systems
Mac 11.0 Big Sur,
Mac 12.0 Monterey or later.
Windows 10, 64-bit.
Windows 11.
Linux
Chrome OS
Power Requirements
Power Supply
1 x Internal 100 – 240V AC.
12V DC Input
1 x +12V DC 4‑pin XLR.
Power Usage
25 W
Physical Specifications
Environmental Specifications
Operating Temperature
0° C to 40° C (32° – 104°F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
,
Frequently Asked Questions about the Blackmagic Design Web Presenter 4K
What resolutions does the Web Presenter 4K support?
The Web Presenter 4K supports streaming in resolutions up to 2160p60 Ultra HD. It also accommodates a variety of other resolutions and frame rates to suit your needs.
Can I use the Web Presenter 4K without a stable internet connection?
Yes, the Web Presenter 4K offers the flexibility to stream using either Ethernet or mobile data, allowing you to broadcast even in areas with limited internet connectivity.
How does the webcam functionality work?
The built-in USB connections of the Web Presenter 4K function like a webcam. This means you can easily connect it to a computer and use it with any streaming software, or even platforms like Skype or Zoom.
Is there any software installation required?
No, the Web Presenter 4K is designed for simplicity. Just connect your video source and Ethernet cable, and you’re ready to stream. There’s no need for complicated software installations or configurations.
What are the physical dimensions of the Web Presenter 4K?
The Web Presenter 4K measures 120 x 120 x 30 mm and weighs 0.4 kg, making it compact and lightweight for easy portability.
