Professional Capture andPlayback for Thunderbolt 3 Computers with the Ultrastudio Mini Recorder!
,
- SD/HD/3G-SDI and Analog Inputs
- HDMI and Dual SDI Outputs
- Thunderbolt 3 Interface
- Supports SD and HD Resolutions
- 4:2:2 and 4:4:4 Color Sampling Support
- 8/10/12-Bit Color Depth
- RS-422 Deck Control
- HD to SD Down-Conversion
,Host ConnectionUSB Type-C (Thunderbolt 3)InputVideo Input Connectors1 x BNC (3G-SDI) Female1 x 3BNC (Component / Composite) FemaleInput Video FormatSDI (4:4:4/4:2:2)DCI 2K at 23.98/24/25 fpsDCI 2KPsF 23.98/24/25 fps1080p 23.98/24/25/29.97/30/50/59.94/60 fps1080PsF 23.98/24/25/29.97/30 fps1080i 50/59.94/60 fps720p 50/59.94/60 fpsNTSCPALAudio Input Connectors2 x 1/4″ TRS Analog FemaleEmbedded Audio InputSDI: 16-ChannelOutputVideo Output Connectors2 x BNC (3G-SDI) Female1 x HDMI (HDMI 1.4b) FemaleOutput Video FormatHDMI (8-Bit 4:4:4 RGB)1080p at 30 fpsSDI (8/10/12-Bit 4:4:4 RGB)1080p at 30 fpsEmbedded Audio OutputSDI: 16-ChannelHDMI: 2-ChannelStandardsVideo Standard ComplianceSMPTE 259M/292M/296M/372M/425M-A/425M-BConnectivityOther I/O1 x DE-9/DB-9 RS-422 Input1 x BNC Reference InputHardwareOS CompatibilityWindows 7 or LatermacOS 10.14 or LaterLinux*As of April, 2020: Check with manufacturer for the most up-to-date compatibilityPower ConnectorNoneEnvironmentalOperating Temperature32 to 104°F / 0 to 40°CStorage Temperature-4 to 113°F / -20 to 45°COperating Humidity0 to 90%GeneralDimensions6.69 x 5.51 x 1.75″ / 16.99 x 14 x 4.45 cmWeight1.34 lb / 608 g
